PILEDYN (PILE group linear DYNamic analysis)

PILEDYN is a software package for PILE group linear DYNamic analysis in the frequency domain based on an advantageous BEM-FEM model for soil-pile interaction:

L.A. Padrón, J.J. Aznárez and O. Maeso. BEM-FEM coupling model for the dynamic analysis of piles and pile groups, 31, pp. 473-484, 2007.

The software package is comprised of three modules:

Pre-processor: GUI-based (MATLAB) or command-line file-based (MATLAB/Octave).
Solver: command-line file-based (executables for 64-bit GNU/Linux or Windows).
Post-processor: command-line file-based (MATLAB/Octave).

In the present version 1.0, it obtains impedance functions of pile groups with one quarter symmetry.

Screenshots

Screenshot of the MATLAB GUI pre-processor

Screenshot of BEM-FEM mesh used for PILEDYN solver

Funding

This work was supported by the Subdirección General de Proyectos de Investigación of the Ministerio de Economía y Competitividad (MINECO) of Spain and FEDER through Research Projects BIA2004-03955-C02-02, BIA2007-67612-C02-01, BIA2010-21399-C02-01 and BIA2014-57640-R.

Download

Windows, 64 bit, LAPACK (single core)
GNU/LINUX, 64 bit, LAPACK (single core)
GNU/LINUX, 64 bit, ATLAS (multi-core)
